Getting the most out of your Yubikey on NixOS

Use cases

There are many different use cases I found for the Yubikeys. I have marked the ones I have succesfully gotten working. Note that I don't necessarily want or endorse the ones I have left undone. This blog post will get updated as I find more use cases.

• 2fa for websites (works out of the box) ✅
• pam auth (sudo/login) ✅
• GPG keys ✅
• Git commit signing ✅
• Encrypting/Decrypting sops secrets ✅
• SSH keys ❓
• Yubikey based full disk encryption (guide) ❓

Pam module

There are two pam modules that implement Yubikey functionality: yubico-pam and pam_u2f, the latter of which seems to be the more modern and recommended approach. I did try yubico-pam but I was unable to get it working.

The pam_u2f module implements the U2F (universal second factor) protocol. The protocol was initially developed by Yubico, Google and NXP and is nowadays hosted as an open-standard by the FIDO Alliance. All current and most legacy Yubikeys support the U2F protocol making this the preferred way to use Yubikeys for user login.

I ended up using the pam_u2f module. This allows the Yubikey to work as a replacement for sudo/login password. The configuration is also completely declarative and I'm able to enroll my Yubikeys, including the backup key, to another device without actually having all of the keys with me. How is this possible?

1. Connect your Yubikey.
2. Create authorization mappings for your keys. This file works similarly to ssh/known_hosts and is not a secret.

nix-shell -p pam_u2f
pamu2fcfg -n -o pam://yubi

3. The command above will look like it just hangs. You have to touch your Yubikey to continue. You will get a public key for your Yubikey printed into the terminal. This key will be different every time you run the command. Save it somewhere, you will need it later.
4. Repeat steps 1-3 for your other Yubikeys.

Enable u2f in your nixos configuration:

security.pam.u2f = {
  enable = true;
  interactive = true;
  cue = true;
};

• interactive: will prompt you with Insert your U2F device, then press ENTER.
• cue: will print Please touch the device. when your action is required.

GPG keypair

Add the following to your nixos system configuration:

services = {
  pcscd.enable = true;
  udev.packages = [ pkgs.yubikey-personalization ];
};

And the following to your home-manager configuration. Most of this is not actually required but they are good hardening steps (apparently...).

disable-ccid is crucial to prevent pcscd daemon and gpg-agent conflicts.

programs.gpg = {
  enable = true;

  # https://support.yubico.com/hc/en-us/articles/4819584884124-Resolving-GPG-s-CCID-conflicts
  scdaemonSettings = {
    disable-ccid = true;
  };

  # https://github.com/drduh/config/blob/master/gpg.conf
  settings = {
    personal-cipher-preferences = "AES256 AES192 AES";
    personal-digest-preferences = "SHA512 SHA384 SHA256";
    personal-compress-preferences = "ZLIB BZIP2 ZIP Uncompressed";
    default-preference-list = "SHA512 SHA384 SHA256 AES256 AES192 AES ZLIB BZIP2 ZIP Uncompressed";
    cert-digest-algo = "SHA512";
    s2k-digest-algo = "SHA512";
    s2k-cipher-algo = "AES256";
    charset = "utf-8";
    fixed-list-mode = true;
    no-comments = true;
    no-emit-version = true;
    keyid-format = "0xlong";
    list-options = "show-uid-validity";
    verify-options = "show-uid-validity";
    with-fingerprint = true;
    require-cross-certification = true;
    no-symkey-cache = true;
    use-agent = true;
    throw-keyids = true;
  };
};

services.gpg-agent = {
  enable = true;

  # https://github.com/drduh/config/blob/master/gpg-agent.conf
  defaultCacheTtl = 60;
  maxCacheTtl = 120;
  pinentryPackage = pkgs.pinentry-curses;
  extraConfig = ''
    ttyname $GPG_TTY
  '';
};

Follow this guide to create a GPG master key, with 3 different subkeys: signing key, encryption key and authentication key. After generating the keys, back them up on a USB stick. Once you have backups, move the keys over to the Yubikey. This is all explained in great detail in the aforementioned guide.

You can create a shell with all the packages you need to follow the guide (assuming you already deployed the configuration above):

nix-shell -p yubikey-manager cryptsetup

If you added the public key URL onto the Yubikey, on any computer you plug the key in, you can now fetch the public key like this:

gpg --edit-card
gpg/card> fetch
gpg/card> quit

gpg --edit-key $KEYID
gpg> trust
Your decision? 5
Do you really want to set this key to ultimate trust? (y/N) y
gpg> quit

The Yubikey can now be used as your GPG keypair!

Git commit signing

We can configure git to use our newly created GPG key to sign commits. Using home-manager: (This can of course be defined in the regular git config file as well)

programs.git = {
  userEmail = "same as your key identity"
  signing.key = "$KEYID";
  extraConfig.commit.gpgsign = true;
};

Now whenever I git commit, the GPG key is pulled from my Yubikey, and the commit is signed. If my Yubikey is not plugged in, the commit will fail to sign.

Decrypting secrets

The Yubikey can be used to decrypt secrets. This again uses the GPG key. I am using sops-nix to manage the secrets of my NixOS hosts, and sops accepts GPG keys in place of the age keys. Simply, in .sops.yaml:

keys:
  - &user 87ECDD306614E5105299F0D4090EB48A4669AA54
  - &host age123456x

creation_rules:
  - path_regex: hosts/host/secrets.yaml$
    key_groups:
      - pgp:
        - *user
        age:
        - *host

What's happening here? I have two keys defined. One is for my user, and it's my GPG key fingerprint (Can be found with gpg --list-secret-keys), and the age key is derived from the SSH key of a remote host.

I have defined both of the keys as possible decryption keys to decrypt hosts/host/secrets.yaml with, in their corresponding groups (pgp and age).

Now when I try to open secrets.yaml, my GPG key is read from the Yubikey, and the file is decrypted. If my Yubikey is not plugged in, I cannot decrypt the file.

Sources

https://nixos.wiki/wiki/Yubikey

https://developers.yubico.com/pam-u2f

https://github.com/drduh/YubiKey-Guide
